The Radix Tripod is a high-quality accessory crafted in-house by CWT to exacting standards. Designed specifically for compatibility with the Sequoia, Redwood, and Cypress table leg systems, this tripod is constructed from durable 6082 T6 aluminium, available in a sleek black or silver powder-coated finish for enhanced durability and style.
This folding tripod allows you to extend the use of your existing Sequoia, Redwood, or Cypress table and legs outdoors, such as in your awning area. It is especially suited for use on soft ground, featuring a hole at the end of each foot where you can remove the rubber feet and secure the tripod firmly to the ground using our Radix Ground Screw Pegs (available separately).
Please note that installing this tripod will raise your table height by 93mm, providing additional elevation when needed. The Radix Tripod must not be used with the MOD/Cypress Hybrid. The cantilevered arm moves the load away from the centre of the tripod and will cause it to tip.
Ideal for enhancing your outdoor setup, the Radix Tripod ensures stability, convenience, and adaptability for your Sequoia ITC furniture collection.
Specifications
- Frame: 6082 aluminium; Construction: 8mm folding legs with model-specific leg adaptor plate
- Finish: black or silver powder coat
- Deployed floor space: 580 x 460mm
- Folded for storage: 395 x 100 x 75mm (L x W x H)
- Weight: 1.8kg
- Table-height increase: +93mm
- Ground-fixing holes: 3 x Ø8mm, concealed beneath removable feet, for pegs or ground fixings
- Model codes: CWT-RAD-SQ-B3 (Sequoia, black), CWT-RAD-SQ-S3 (Sequoia, silver), CWT-RAD-CY-B3 (Cypress/Redwood, black), CWT-RAD-CY-S3 (Cypress/Redwood, silver)
- Use only on firm, level ground with all three legs fully open and the load centred; not compatible with the MOD/Cypress Hybrid or another cantilevered system
- For table tops above approx. 750 x 500mm, use suitable ground fixings where conditions permit
- Designed and manufactured in the United Kingdom
